Shelly Pro Dimmer 0/1-10V PM
£82.59
The Shelly Pro Dimmer 0/1-10V PM is a smart dimming controller for driving 0-10V and 1-10V dimmable LED drivers from a phone, tablet, PC, or home automation system. It's a current-sourcing controller that works standalone over Wi-Fi or through cloud services, with built-in power measurement and support for up to 16A of switching current.
- Supports both 0-10V and 1-10V driver types
- Current-sourcing controller with power measurement
- Handles up to 16A switching current
- Supports HTTP/HTTPS webhooks and custom mJS scripts
Buy the Shelly Pro Dimmer 0/1-10V PM online in the UK from ShellyUK — genuine Shelly stock with fast UK delivery.
Shelly Dimmer 0/1-10V PM Gen3 is a smart dimming controller which allows remote control dimming drivers through a mobile phone, tablet, PC, or home automation system. It can work standalone in a local Wi-Fi network or it can also be operated through cloud home automation services. The device is a current sourcing controller and provides support for 0-10V and 1-10V types of drivers.
Supports both 0-10V and 1-10V driver types
Current-sourcing controller with power measurement
Handles up to 16A switching current
Supports HTTP/HTTPS webhooks and custom mJS scripts
Where you'd use it
Commercial LED Driver Retrofit
Control a bank of 0-10V dimmable LED drivers in a shop or office ceiling from the consumer unit, avoiding separate dimmer modules at every fitting.
Scripted Lighting Scenes
Use custom mJS scripts and webhooks to fire scheduled dimming scenes, such as a gradual morning brighten-up in a commercial space.
Power-Verified Dimming Feedback
Feed the built-in power measurement into a wider building management setup to confirm a lighting circuit really dimmed rather than just trusting the command.
Specification
Connectivity
- HTTP/HTTPS webhooks
- Yes
- Wi-Fi Protocol
- 802.11 b/g/n
- Wi-Fi Radio frequency
- 2412 - 2472 MHz
- Wi-Fi Radio signal power
- 1mW
- WiFi range (depending on local construction) • up to
- 50 m outdoors • up to 30 m indoors
- Bluetooth
- Yes
- Bluetooth Protocol
- 4.2
- Bluetooth Range • up to
- 30m/100ft outdoors • up to 10m/33ft indoors
Protection & Safety
- Device temperature protection
- Yes
Physical & Build
- (H x W x D)
- 94 x 19 x 69 ±0.5 mm / 3.70 x 0.75 x 2.71 ±0.02 in
Environmental
- Operational temperature
- -20°C to + 40°C
Power & Electrical
- Power supply
- AC 110-230V ±10%, 50/60Hz
- Maximum switching voltage
- 240V~
- Electrical consumption < 3W
- 0-10V/1-10V voltage control type Current sourcing
Smart Features
- Power measurement
- Yes
- Custom scripts(mJs)
- Yes
Other
- Maximum switching current
- 16A
- Maximum control current
- 35mA
